Selectronic

Ultima™ Selectronic Touchless Urinal Flush Valve, Piston-Type, PWRX, 0.125 gpf/0.5 Lpf

List Price:

List Price:

Model: 6064013.002

View in Scene
link
  • For urinals with 3/4-inch (19 mm) exposed top spud
  • 10-Year PWRX Battery installed in valve
  • Touchless operation limits the spread of germs
  • Exclusive DynaClean® self-cleaning wiper spring technology
  • Integral wiper spring cleans refill orifice with every flush to help prevent valve run-on
Finish: Polished Chrome
  • Polished Chrome

Product Description

The optional PWRX™ Long-Life Battery System features advanced battery and electronics for a 10 year battery life to reduce the downtime and maintenance costs associated with changing batteries.

Ultima™ Selectronic Touchless Urinal Flush Valve, Piston-Type, PWRX, 0.125 gpf/0.5 Lpf

Selectronic

Ultima™ Selectronic Touchless Urinal Flush Valve, Piston-Type, PWRX, 0.125 gpf/0.5 Lpf

Features

  • For urinals with 3/4-inch (19 mm) exposed top spud
  • 10-Year PWRX Battery installed in valve
  • Touchless operation limits the spread of germs
  • Exclusive DynaClean® self-cleaning wiper spring technology
  • Integral wiper spring cleans refill orifice with every flush to help prevent valve run-on
  • Fully mechanical manual override can operate without power
  • Fail-Safe operation: Valve automatically closes upon loss of power or water pressure
  • Pressure Compensation feature ensures accurate flush volume regardless of inlet water pressure
  • Proprietary brass alloy resists dezincification
  • 11-1/2" (292 mm) rough-in

Innovations

ada

ADA Compliant

Meets the Americans with Disabilities Act guidelines and ANSI A117.1 requirements for accessible and usable building facilities - check local codes.

CALGreen

water efficient

Water Efficient

WaterSense

WaterSense® Certified. Meets all ANSI/ASME low consumption, water conservation requirements.

Specifications

Parts for this product

Following are the list of products or parts which you can also add to your list along with the product, you can also download the parts diagram by clicking on the Download Repair Parts Diagram button

Installation
